Modulaire uitvoering (voor railmontage): Nee
Nom. vermogen bij AC-3, 400 V: 3 Kilowatt
Aantal hoofdcontacten als maakcontact: 3
Aantal hoofdcontacten als verbreekcontact: 0
Aantal hulpcontacten als maakcontact: 1
Aantal hulpcontacten als verbreekcontact: 0
Nom. bedrijfsstroom Ie bij AC-3, 400 V: 6.600 Ampère
Nom. bedrijfsstroom Ie bij AC-1, 400 V: 22 Ampère
Nom. stuurspanning Us bij AC 50HZ: 0 - 0 Volt
Nom. stuurspanning Us bij AC 60HZ: 0 - 0 Volt
Nom. stuurspanning Us bij DC: 24 - 24 Volt
Aansluitwijze hoofdstroomcircuit: Schroefaansluiting
Type stuurspanning: DC
Nom. bedrijfsstroom Ie bij AC-4, 400 V: 5 Ampère
Nom. vermogen bij AC-4, 400 V: 2.200 Kilowatt
Nom. vermogen NEMA: 2.200 Kilowatt
